1-15
Introducing the Switch
Features
Features
Figure 2. Front of the al 10-GbE CX4 Module
The al Modules have the following features:
■ Connectivity ports.
■ LEDs that provide information for each port on the link and mode status.
■ LED that provides information on module status.
■ “hot swap transceiver” support—you can add, replace, or change the type
of any of the transceivers that you use in the SFP+ module ports, without
having to first remove the module, and without having to shut down the
switch.
Standards adherence:
■ IEEE 802.3ak CX4
■ IEEE 802.3ae XAUI
Note The al modules are not “Hot-swappable”.
HP ProCurve 10-GbE CX4 al Module
Module Status
LEDs
Retaining screw
Copper CX4 port connections
Link and Mode LEDs
(one pair per port)
