2-18
Installing the Switch
Installation Procedures
Installing the Switch
To remove the mini-GBICs that have the plastic tab or plastic collar, push the
tab or collar toward the switch until you see the mini-GBIC release from the
switch (you can see it move outward slightly), and then pull it from the slot.
To remove the mini-GBICs that have the wire bail, lower the bail until it is
approximately horizontal, and then using the bail, pull the mini-GBIC from the
slot.
7. Connect the Switch to a Power Source
1. Plug the included power cord into the switch’s power connector and into
a nearby AC power source.
2. Re-check the LEDs during self test. See “LED Behavior” on page 2-7. Also
check the LEDs for any accessories you may have installed.
8. (Optional) Connect an External Power Supply
The 2910al Switches support two types of external power supplies:
■ The J8696A, HP ProCurve 620 Redundant and External Power Supply (620
RPS/EPS) for RPS power only. The 2910al switches support the RPS or
the redundant portion of the 620 RPS/EPS. Redundant power to one of up
to two switches can be supplied to back up the internal switch power
supply in case of the internal power supply fails. If it should fail, power
will be supplied from the 620 RPS/EPS.
■ The J9443A, HP ProCurve 630 Redundant and/or External Power Supply
(HP ProCurve 630 RPS/EPS) for RPS and EPS power. The 2910al switches
support both the RPS and the EPS of the HP ProCurve 630 RPS/EPS.
These external power supplies are unmanaged power supplies that only
provide information by way of the LEDs.
RPS Operation
The RPS portion of the 620 RPS/EPS and the HP ProCurve 630 RPS/EPS
monitors the power signal from the switch by detecting that either the 620
RPS/EPS or HP ProCurve 630 RPS/EPS is connected to a switch with an RPS
cable. When the power from the switch is no longer detected, the external
power supply will provide power to the switch within 1 millisecond. AC power
must be provided to the switch prior to the RPS being able to provide power.
Software will enable RPS capability, thus boot must be complete.
