2-32
Installing the Switch
Sample Network Topologies
Figure 2-24. Example, PoE edge deployment
ProCurve Switch 5406zl
10 Gigabit copper
cables
10 Gigabit fiber cable
ProCurve Switch 2910al
Gigabit copper
cable
PCs, peripherals and
access points
Servers
