WARNING! Avoid moving parts. You are recommended to wear gloves.
Moving part Wear gloves
For more safety information, please see
Safety precautions on page 3
CAUTION: While cleaning, be careful not to damage the plastic encoder strip located on top of the rod.
4. Wait until the rod is dry, then close the window. The carriage moves to the left side of the printer so that
you can reach the part of the rod under the right cover.
5. Open the printer window.
6. Clean the carriage rod area under the right cover as described in step 3.
7. Take the bottle of oil from the Maintenance Kit that is supplied with your printer (a replacement kit can
be ordered if necessary).
144 Chapter 7 Hardware maintenance ENWW
