The table above shows the resolutions supported by the printer. See your RIP documentation to find the
resolutions supported by your RIP.
Table 11-5 Printing speeds
Passes Approximate printing speed (m²/h)
HP Latex 360 HP Latex 330 HP Latex 310
2 65.5 45.1 42.4
4 31.1 24.8 24.1
6 22.8 14.8 14.2
8 17.1 12.4 12.0
10 13.9 9.9 9.7
12 11.5 8.3 8.0
16 6.4 6.2 6.0
18 5.7 5.0 4.7
20 5.0 4.5 4.2
NOTE: Environmental conditions, job length, and ink density influence the maximum speed you can achieve
with a particular print mode. Special-purpose options such as the use of the ink collector also have an effect
on printing speed.
Table 11-6 Margins
Side margins 5 mm (0.2 in), or 10 mm (0.4 in) with edge holders
Top margin (leading edge) 5 mm (0.2 in)
Bottom margin (trailing edge) 5 mm (0.2 in) (none)
100 mm (3.9 in) (small)
150 mm (5.9 in) (normal)
200 mm (7.9 in) (extra)
300 mm (11.8 in) (extra)
400 mm (15.7 in) (extra)
500 mm (19.7 in) (extra)
NOTE: When the ink collector is in use with the 360 printer, full bleed is available (no side margins).
ENWW Functional specifications 167
