10. Pull down the center of the substrate's leading edge to straighten the substrate. Do not attempt to pull
more substrate out of the printer.
NOTE: If you are loading the take-up reel during printing, you do not need to pull the substrate taut.
Tape the substrate to the core when an adequate length of substrate has fed from the printer after
printing begins.
WARNING! Do not touch the printer's curing enclosure, which could be hot.
Risk of burns
For more safety information, please see
Safety precautions on page 3
11. Adjust the position of the core on the take-up reel so that it is aligned with the substrate.
12. Tape the leading edge of the substrate to the core in the center, then at each side. Make sure that the
substrate is straight.
NOTE: Depending on whether you want to print the images facing in or out, place the tape
accordingly. See below.
ENWW The take-up reel 71
