Connecting the AP
Attaching the grounding wire and antennas
1. Refer to Figure 10. Remove the grounding screw (1) from lug on the AP body.
Figure 10 Grounding cable
2. Grounding cable1. Grounding screw
2. Attach a grounding cable (2), #10 AWG or thicker, with the grounding screw (1).
3. Tighten the grounding screw and ensure that the cable is firmly anchored. Ensure that the
other end of the grounding wire is connected to an earth ground.
4. Install antennas including antenna connector lightning arresters as described in the respective
antenna guide available online (search by antenna part number). An HP Lightning Arrester
(J8996A) Guide is also available online.
Connecting the AP 15
