HP mt41 User Manual

Category Description
Wireless Integrated wireless local area network (WLAN) options by way of wireless module
Two WLAN antennas built into display assembly
Support for the following WLAN formats:
●
Atheros 802.11 b/g/n 1×1 + Bluetooth 4.0 Combo Adapter
● Broadcom 802.11 a/b/g/n 2×2 + Bluetooth 4.0 Combo Adapter
Integrated wireless wide area network (WWAN) options by way of wireless module
(select models only)
Two WWAN antennas (world-wide 5 band) built into display assembly
Security provided by subscriber identity module (SIM), slot located in battery bay
Support for the following WWAN formats:
● HP lt4111 LTE/EV-DO/HSPA+ Mobile Broadband Module
●
HP lt4112 LTE/HSPA+ Mobile Broadband Module
Support for no WWAN option
External media cards HP 2-in-1 multiformat Digital Media Reader Slot. Reads data from and writes data to
digital memory cards such as Secure Digital (SD).
Ports ● AC adapter, HP Smart
●
Audio-in (mono microphone)/audio-out (stereo headphone) combo jack
●
DisplayPort 1.2
● Docking
●
RJ-45 (Ethernet)
●
USB 2.0* (3)
●
USB 2.0* charging (1)
●
VGA (Dsub 15 pin) supporting: 1920×1200 external resolution @ 75 Hz, hot plug
and unplug and autodetection for correct output to wide-aspect versus standard
aspect video
* These ports support USB 2.0 by default. For details about activating the USB 3.0
port functionality, see the User Guide.
Keyboard/pointing devices Full-size chiclet keyboard
Spill resistant with drain
TouchPad requirements:
● On/off button
●
Support for 2-way scroll
●
Taps enabled by default
●
Gestures enabled by default:
◦
2-finger scrolling
◦
2-finger zoom (pinch)
Power requirements Support for 65 W, HP Smart Adapter
2 Chapter 1 Product description

HP mt41 Specifications

General

Form factor	Clamshell
Product type	Mobile thin client
Product color	Silver
Country of origin	China
Processor cache	1 MB
Processor cores	2
Processor model	A4-5150M
Processor family	AMD A4
Processor frequency	2.7 GHz
Processor manufacturer	AMD
Processor boost frequency	3.3 GHz
Motherboard chipset	AMD A76M FCH
Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory clock speed	1600 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	8 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
Storage media	SSD
Optical drive type	No
Card reader integrated	Yes
Total storage capacity	16 GB
Compatible memory cards	SD
Number of SSDs installed	1
Display surface	-
Display diagonal	14 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Discrete graphics card model	Not available
On-board graphics card model	AMD Radeon HD 8350G
On-board graphics card family	AMD Radeon HD 8000
Wi-Fi standards	802.11a, 802.11b, 802.11g
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile network generation	3G
Charging port type	DC-in jack
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
Pointing device	Touchpad
Operating system installed	Windows Embedded Standard
Battery capacity	55 Wh
Battery life (max)	8.5 h
Number of battery cells	6
AC adapter power	65 W

Weight and Dimensions

Depth	237 mm
Width	340 mm
Height	25.3 mm
Weight	2080 g
