Display assembly subcomponents
Item Component Spare part number
(1) Display bezel 738712-001
(2) Microphone module
Webcam/microphone module 738409-001
Microphone only module 738397-001
(3) Display panel, 14 in (35.56 cm), WLED, HD, AG, SVA, flat display panel 747751-001
(4) Left and right display hinges (included in Display Hinge Kit) 738396-001
(5) Display panel cable (includes webcam/microphone module cable and tape) 738684-001
(6) Display back cover (includes WLAN and WWAN antenna cables and gaskets) 738680-001
20 Chapter 3 Illustrated parts catalog
