HP mt41 User Manual

9 Statement of Volatility
The purpose of this document is to provide general information regarding non-volatile memory in
industry-standards based HP Business Notebook PC systems and provide general instructions for
restoring nonvolatile memory that can contain personal data after the system has been powered off
and the hard drive has been removed.
HP Business Notebook PC products that use AMD®-based system boards contain volatile DDR
memory. The amount of nonvolatile memory present in the system depends upon the system
configuration. AMD-based system boards contain nonvolatile memory subcomponents as originally
shipped from HP assuming that no subsequent modifications have been made to the system and
assuming that no applications, features, or functionality have been added to or installed on the
system.
Following system shutdown and removal of all power sources from an HP Business Notebook PC
system, personal data can remain on volatile system memory (DIMMs) for a finite period of time and
will also remain in nonvolatile memory. The steps below will remove personal data from the notebook
PC, including the nonvolatile memory found in AMD-based system boards. Some of these steps are
disclosed in the Maintenance & Service Guides available for HP PC products available on the product
support pages at
www.hp.com.
1. Follow steps (a) through (j) below to restore the nonvolatile memory that can contain personal
data. Restoring or re-programming nonvolatile memory that does not store personal data is
neither necessary nor recommended.
a. Enter BIOS (F10) Setup by powering on the system and pressing F10 when prompted near
the bottom of the display, or press the ESC key to display the start up menu, then press
F10. If the system has a BIOS administrator password, enter the password at the prompt.
b. Select Main > Restore Defaults.
c. Select the Security menu, and then Restore Security Level Defaults.
d. If an asset or ownership tag is set, select the Security menu and scroll down to the
Utilities menu. Select System IDs, and the select Asset Tracking Number. Press the
spacebar once to clear the tag, then press Enter to return to the prior menu.
e. If a DriveLock password is set, select the Security menu, scroll down to Hard Drive Tools
under the Utilities menu, select Hard Drive Tools, select DriveLock, then uncheck
DriveLock password on restart.
f. If an Automatic DriveLock password is set, select the Security menu, scroll down to Hard
Drive Tools under the Utilities menu, select Hard Drive Tools, scroll down to Automatic
DriveLock, then select the desired hard drive and disable protection. At the automatic drive
lock warning screen, select Yes to continue. Repeat this procedure if more than one hard
drive has an Automatic DriveLock password.
g. Select the Main menu, then Reset BIOS Security to factory default. Click yes at the
warning message.
h. Select the Main menu, then Save Changes and Exit.
89

HP mt41 Specifications

General

Form factor	Clamshell
Product type	Mobile thin client
Product color	Silver
Country of origin	China
Processor cache	1 MB
Processor cores	2
Processor model	A4-5150M
Processor family	AMD A4
Processor frequency	2.7 GHz
Processor manufacturer	AMD
Processor boost frequency	3.3 GHz
Motherboard chipset	AMD A76M FCH
Memory slots	2x SO-DIMM
Internal memory	4 GB
Memory clock speed	1600 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	8 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
Storage media	SSD
Optical drive type	No
Card reader integrated	Yes
Total storage capacity	16 GB
Compatible memory cards	SD
Number of SSDs installed	1
Display surface	-
Display diagonal	14 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Discrete graphics card model	Not available
On-board graphics card model	AMD Radeon HD 8350G
On-board graphics card family	AMD Radeon HD 8000
Wi-Fi standards	802.11a, 802.11b, 802.11g
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile network generation	3G
Charging port type	DC-in jack
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
Pointing device	Touchpad
Operating system installed	Windows Embedded Standard
Battery capacity	55 Wh
Battery life (max)	8.5 h
Number of battery cells	6
AC adapter power	65 W

Weight and Dimensions

Depth	237 mm
Width	340 mm
Height	25.3 mm
Weight	2080 g
