4. Slide the service door toward the front of the computer (4), and then lift to remove the
service door (5).
Reverse this procedure to install the service door.
Hard drive
NOTE: The hard drive spare part kit includes the hard drive bracket, cable and screws.
Description Spare part number
16 GB, SATA SSD 750751-001
Before removing the hard drive, follow these steps:
1. Turn off the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect the power from the computer by unplugging the power cord from the computer.
3. Disconnect all external devices from the computer.
4. Remove the battery (see
Battery on page 32).
5. Remove the service door (see
Service door on page 33).
34 Chapter 5 Removal and replacement procedures for Customer Self-Repair parts
