HP P2000 G3 SAS MSA System User Guide 67
NOTE: Connections to this device must be made with shielded cables – grounded at both ends – with
metallic RFI/EMI connector hoods, in order to maintain compliance with FCC Rules and Regulations.
Physical requirements
The floor space at the installation site must be strong enough to support the combined weight of the rack,
controller enclosures, drive enclosures (expansion), and any additional equipment. The site also requires
sufficient space for installation, operation, and servicing the enclosures, and sufficient ventilation to allow a
free flow of air to all enclosures.
Table 19 and Table 20 list enclosure dimensions and weights. Weights are based on an enclosure having
a full complement of disk drives, two controller or expansion modules, and two power supplies installed.
“2U12” denotes the LFF enclosure and “2U24” denotes the SFF enclosure. The SFF is further delineated by
the standard-depth 2U24 and the new reduced-depth (short) 2U24.
Table 20 provides weight data for P2000 G3 controller enclosures and select drive enclosures. For
information about other HP MSA drive enclosures that may be cabled to these systems (e.g., MSA70 or
D2700), check Quickspecs, which can be found from your HP MSA products page
http://www.hp.com/go/msa
. Select your product. Quickspecs links are located on the right.
.
.
Table 19 Rackmount enclosure dimensions
Specifications Rackmount
2U Height (y-axis) 3.5 inches (8.9 cm)
Width (x-axis):
• Chassis only
• Chassis with bezel ear caps
17.6 inches (44.7 cm)
18.9 inches (47.9 cm)
Depth (z-axis):
SFF standard-depth drive enclosure (2U24)
• Back of chassis ear to controller latch
• Front of chassis ear to back of cable bend
SFF reduced-depth drive enclosure (2U24)
• Back of chassis ear to controller latch
• Front of chassis ear to back of cable bend
LFF drive enclosure (2U12)
• Back of chassis ear to controller latch
• Front of chassis ear to back of cable bend
20.7 inches (52.6 cm)
23.6 inches (59.9 cm)
19.9 inches (50.5 cm)
22.8 inches (57.9 cm)
23.7 inches (60.2 cm)
26.4 inches (67.1 cm)
Table 20 Rackmount enclosure weights
Specifications Rackmount
P2000 G3 MSA SFF controller enclosure (standard)
• Chassis with FRUs (no disks)
1, 2
• Chassis with FRUs (including disk)
1,3
21.4 lb (9.7 kg) [chassis]
46.4 lb (21.0 kg)
58.4 lb (26.5 kg)
P2000 G3 MSA SFF controller enclosure (reduced)
• Chassis with FRUs (no disks)
1, 2
• Chassis with FRUs (including disk)
1,3
19.0 lb (8.6 kg) [chassis]
44.0 lb (19.9 kg)
56.0 lb (25.4 kg)
P2000 G3 MSA LFF controller enclosure
• Chassis with FRUs (no disks)
1, 2
• Chassis with FRUs (including disks)
1,3
22.0 lb (9.9 kg) [chassis]
47.0 lb (21.3 kg)
68.0 lb (30.8 kg)
