HP P24v G4 User Manual

1
1 Getting started
Read this chapter to learn about safety information and where to find additional HP resources.
Important safety information
Carefully read the cautions and notes within this document to minimize the risk of personal injury to
service personnel. The cautions and notes are not exhaustive. Proper service methods are important to
the safe, reliable operation of equipment. Improper service methods can damage equipment.
The service procedures recommended and described in this service manual provide effective methods of
performing service operations. Service engineers should have prior repair knowledge and experience as
well as appropriate training for the product before performing service procedures.
● Be sure your working environment is dry and clean and meets all government sa
fety
requi
rements.
● Be sure that other persons are safe while you are servicing the product.
● Do not perform any action that can cause a hazard to the customer or make the product unsafe
.
● Use pro
per safety devices to ensure your perso
nal safety.
● Always u
se approved tools and test equipment for servicing.
● Never assume the product’s power is disconnected from the main power supply. Chec
k that it
is disco
nnected before opening the product’s cabinet
.
● Module
s containing electrical components are sensitive to electrostatic discharg
e (ESD).
F
ollow ESD safety procedures while handling these parts.
● Some products contain more than one battery. Do not disassemble or expose a ba
ttery to high
temperature
s, such as throwing into fire,
or the battery may explode.
● Refer to gove
rnment requirements for battery recycling or disposal.
This information provides general service information for the monitor. Adherence to the
procedures and precautions is essential for proper service.
IMPORTANT: Only
trained service personnel who are familiar with this HP product should perform service
or maintenance for it. Before performing any service or maintenance, personnel must read the important
safety information.
IMPORTANT: Y
ou must disconnect the power cord from the power source before opening the monitor
to prevent component damage.
Important service information and precautions
● Repair must be performed by professional service technicians in a repair center. End users
sho
uld not perform these procedures.
● Please note during servicing that the primary side is the high voltage area
.
● This mo
nitor meets ROHS requirements. Be sure to use lead-free solder wire when soldering.
● If you must change a capacitor, be sure to match the polarity as printed on the PC
B.
● If you must replace a ca
pacitor, make sure the specification and part number match the BOM
and location.

HP P24v G4 Specifications

General

Color gamut	72 %
Screen shape	Flat
Display diagonal	23.8 \
Display technology	-
Native aspect ratio	16:9
Maximum refresh rate	60 Hz
Contrast ratio (dynamic)	8000000:1
Contrast ratio (typical)	1000:1
Display brightness (typical)	250 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1440 x 900 (WXGA+), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080)
HDMI	Yes
HDMI version	1.4
Panel mounting interface	100 x 100 mm
Power consumption (off)	0.5 W
Power consumption (standby)	23.5 W
Power consumption (typical)	26 W
HP segment	Business
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR
Product color	Black
Package depth	123 mm
Package width	588 mm
Package height	373 mm
Package weight	4700 g

Weight and Dimensions

Depth (with stand)	186.1 mm
Width (with stand)	539.6 mm
Height (with stand)	405 mm
Weight (with stand)	3460 g
Depth (without stand)	47.6 mm
Height (without stand)	325 mm
