HP Pro 3330 Microtower User Manual

Spare part
number
Description
663100-001 System board for use in 3340/3348 models without Windows 8 (includes thermal material)
663101-001 System board for use in 3335/3385 models (includes thermal material)
663213-001 HP USB 3.0 SuperSpeed PCIe x1 card
663214-001 USB 3.0 SuperSpeed power extension cable
665120-001 Intel Core i3 2130 processor, 3.4 GHz, 3-MB L3 cache (includes thermal material)
665121-001 Intel Core i5 2320 processor, 3.0 GHz, 6-MB L3 cache (includes thermal material)
665122-001 Intel Pentium Dual-Core G630 processor, 2.7 GHz, 3-MB L3 cache (includes thermal material)
665123-001 Intel Pentium Dual-Core G860 processor, 3.0 GHz, 3-MB L3 cache (includes thermal material)
665467-001 Intel Celeron G440 processor, 1.6 GHz, 1-MB L3 cache (includes thermal material)
666330-001 ATI Radeon HD 6450 1-GB graphics adapter, PCIe x16
666885-001 Speaker with rubber rivets
666886-001 AMD Athlon X2 B30 processor, 3.6 GHz, 2-MB L2 cache (includes thermal material)
666887-001 AMD Athlon X2 250 processor, 3.0 GHz, 2-MB L2 cache (includes thermal material)
666888-001 AMD Phenom X2 B60 processor, 3.5 GHz, 2-MB L2 cache (includes thermal material)
666889-001 AMD Sempron X2 190 processor, 2.5 GHz, 1-MB L2 cache (includes thermal material)
666891-001 Intel Celeron Dual-Core G530 processor, 2.4 GHz, 2-MB L3 cache (includes thermal material)
666892-001 Intel Celeron Dual-Core G540 processor, 2.5 GHz, 2-MB L3 cache (includes thermal material)
667719-001 1-TB, 7200 rpm hard drive
667720-001 500 GB, 7200 rpm hard drive
667727-001 Fan sink for use in models with Intel processors (includes replacement thermal material)
667854-001 SATA3 cable, 254 mm
668571-001 Front bezel for use on 3330 models
668572-001 Front I/O and USB assembly
670439-AA1 Front bezel for use in the People’s Republic of China
682410-001 Intel Celeron G460 processor, 1.8 GHz, 1-MB L3 cache (includes thermal material)
682411-001 ATI Radeon HD 7450 1-GB graphics adapter
684236-001 320 GB, 5400 rpm hard drive
684237-001 500 GB, 5400 rpm hard drive
684591-001 nVidia GeForce GT630 2-GB graphics adapter, PCIe x16
686217-001 500 GB, 7200 rpm hard drive, 2.5 inch
688950-001 Intel Core i3 3220 processor, 3.3 GHz, 3-MB L3 cache (includes thermal material)
688951-001 Intel Core i3 3240 processor, 3.4 GHz, 3-MB L3 cache (includes thermal material)
689578-001 Intel Core i3 3225 processor, 3.3 GHz, 3-MB L3 cache (includes thermal material)
691934-001 Intel Celeron G550 processor, 2.6 GHz, 2-MB L3 cache (includes thermal material)
30 Chapter 4 Illustrated parts catalog

HP Pro 3330 Microtower Specifications

General

Product type	PC
Motherboard chipset	Intel® H61
Tcase	65.3 °C
Bus type	DMI
FSB Parity	No
Processor cache	3 MB
Processor cores	2
Processor model	i3-3220
System bus rate	5 GT/s
Processor family	Intel® Core™ i3
Processor series	Intel Core i3-3200 Desktop Series
Processor socket	LGA 1155 (Socket H2)
Processor threads	4
Processor codename	Ivy Bridge
Processor frequency	3.3 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor operating modes	64-bit
ECC supported by processor	Yes
PCI Express configurations	1x16, 2x8
Thermal Design Power (TDP)	55 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	33
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	1333, 1600 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	32 GB
Memory slots	2x DIMM
Internal memory	4 GB
Memory channels	Dual-channel
Memory clock speed	1333 MHz
Maximum internal memory	8 GB
Memory layout (slots x size)	1 x 4 GB
HDD size	3.5 \
HDD speed	7200 RPM
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi
Total storage capacity	500 GB
Number of SSDs installed	0
Cooling type	-
On-board graphics card ID	0x152
On-board graphics card model	Intel® HD Graphics 2500
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1050 MHz
Number of displays supported (on-board graphics)	3
Recovery operating system	Windows 8 Pro
Operating system installed	Windows 7 Professional
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
USB 2.0 ports quantity	6
Chassis type	Micro Tower
Product color	Black
Country of origin	China
Processor ARK ID	65693
Processor package size	37.5 x 37.5 mm
Supported instruction sets	AVX, SSE4.1, SSE4.2
Thermal solution specification	PCG 2011C
Intel Secure Key Technology version	0.00
Intel Identity Protection Technology version	1.00
Power supply	300 W
Power supply input voltage	100 - 240 V
Power supply input frequency	50 - 60 Hz

Weight and Dimensions

Depth	421.1 mm
Width	173.2 mm
Height	382.3 mm
Weight	10000 g
