HP Pro 3330 Microtower User Manual

Spare part
number
Description
691935-001 Intel Pentium Dual-Core G640 processor, 2.8 GHz, 3-MB L3 cache (includes thermal material)
691936-001 Intel Pentium Dual-Core G870 processor, 3.1 GHz, 3-MB L3 cache (includes thermal material)
697246-001 ATI Radeon HD 6350 512-MB graphics adapter
700578-001 nVidia Quadro NVS300 PCIe x16 graphics card, 512 MB for use in models with Windows 8
701428-281 Keyboard, PS2, for use in Thailand
701428-371 Keyboard, PS2, for use internationally
701428-AA1 Keyboard, PS2, for use in the People’s Republic of China
701428-AB1 Keyboard, PS2, for use in Taiwan
701428-D61 Keyboard, PS2, for use in India
701428-KD1 Keyboard, PS2, for use in Korea
701429-281 Keyboard, USB, for use in Thailand
701429-371 Keyboard, USB, for use internationally
701429-AA1 Keyboard, USB, for use in the People’s Republic of China
701429-AB1 Keyboard, USB, for use in Taiwan
701429-D61 Keyboard, USB, for use in India
701429-KD1 Keyboard, USB, for use in Korea
702084-001 nVidia GeForce GT630 2-GB graphics adapter, PCIe x16 for use in models with Windows 8
702643-001 320 GB, 7200 rpm hard drive
702644-001 System board for use in 3330 models with Windows 8 with no Digital Product Key (DPK) (includes thermal
material)
702644-501 System board for use in 3330 models with Windows 8 Standard (includes thermal material)
702644-601 System board for use in 3330 models with Windows 8 Professional (includes thermal material)
702647-001 ATI Radeon HD 7450 1-GB graphics adapter for use in models with Windows 8
702648-001 nVidia GeForce GT505 512-MB graphics adapter, PCIe x16 for use in models with Windows 8
707247-001 System board for use in 3335/3385 models with NetClone (includes thermal material)
711493-001 System board for use in 3330 models with NetClone (includes thermal material)
711494-001 System board for use in 3340/3348 models with NetClone (includes thermal material)
Microtower (MT) Chassis Spare Parts 31

HP Pro 3330 Microtower Specifications

General

Product type	PC
Motherboard chipset	Intel® H61
Tcase	65.3 °C
Bus type	DMI
FSB Parity	No
Processor cache	3 MB
Processor cores	2
Processor model	i3-3220
System bus rate	5 GT/s
Processor family	Intel® Core™ i3
Processor series	Intel Core i3-3200 Desktop Series
Processor socket	LGA 1155 (Socket H2)
Processor threads	4
Processor codename	Ivy Bridge
Processor frequency	3.3 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor operating modes	64-bit
ECC supported by processor	Yes
PCI Express configurations	1x16, 2x8
Thermal Design Power (TDP)	55 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	33
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	1333, 1600 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	32 GB
Memory slots	2x DIMM
Internal memory	4 GB
Memory channels	Dual-channel
Memory clock speed	1333 MHz
Maximum internal memory	8 GB
Memory layout (slots x size)	1 x 4 GB
HDD size	3.5 \
HDD speed	7200 RPM
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi
Total storage capacity	500 GB
Number of SSDs installed	0
Cooling type	-
On-board graphics card ID	0x152
On-board graphics card model	Intel® HD Graphics 2500
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1050 MHz
Number of displays supported (on-board graphics)	3
Recovery operating system	Windows 8 Pro
Operating system installed	Windows 7 Professional
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
USB 2.0 ports quantity	6
Chassis type	Micro Tower
Product color	Black
Country of origin	China
Processor ARK ID	65693
Processor package size	37.5 x 37.5 mm
Supported instruction sets	AVX, SSE4.1, SSE4.2
Thermal solution specification	PCG 2011C
Intel Secure Key Technology version	0.00
Intel Identity Protection Technology version	1.00
Power supply	300 W
Power supply input voltage	100 - 240 V
Power supply input frequency	50 - 60 Hz

Weight and Dimensions

Depth	421.1 mm
Width	173.2 mm
Height	382.3 mm
Weight	10000 g
