Display components
Table 3-2 Display components and their descriptions
Item Description Spare part number
(1) Display bezel
Models without a camera L45116-001
Models with an HD camera L45114-001
Models with an HD+IR camera L45115-001
(2) Display panel (raw)
FHD, UWVA L52212-001
FHD, UWVA, 250 nits L62785-001
HD, SVA L52213-001
(3) Display/camera cable assembly (models with an HD camera) L45144-001
Display/camera cable assembly (models with an HD+IR camera; not illustrated) L45145-001
20 Chapter 3 Illustrated parts catalog
