HP ProBook 455R G6 User Manual

Power connector cable
Table 6-12 Power connector cable description and part number
Description Spare part number
Power connector cable L01048-001
Before removing the power connector cable, follow these steps:
1. Prepare the computer for disassembly (Preparation for disassembly on page 32).
2. Place the computer in Battery Safe mode (Battery Safe mode on page 32).
3. Remove the bottom cover (Bottom cover on page 33).
4. Remove the battery (Battery on page 41).
5. Remove the display (Display assembly on page 57).
Remove the power connector cable:
1. Remove the two Torx T8 2.5 × 4.0 screws from the right hinge (1).
2. Rotate the hinge up from atop the power connector (2).
3. Disconnect the cable from the system board (3).
4. Remove the connector up and out of the computer (4).
Reverse this procedure to install the power connector cable.
Component replacement procedures 65

HP ProBook 455R G6 Specifications

General

Operating System	Windows 10 Pro
Processor	AMD Ryzen 5 3500U
Graphics	AMD Radeon Vega Graphics
Display	15.6-inch, 1920 x 1080 pixels
RAM	Up to 32GB DDR4
Storage	256GB SSD
Weight	2.0 kg
Battery	3-cell, 45 Wh Li-ion
Ports	1 x USB-C, 1 x HDMI, 1 x headphone/microphone combo
Wireless	Bluetooth 4.2
