Table 3-2 Display components and their descriptions (continued)
Item Description Spare part number
(4) Camera module (HD camera) L45118-001
(5) Camera module (HD+IR camera) L45119-001
Microphone board (includes protective tape; not illustrated) L65700-001
(6) WLAN antennas (dual antennas) L45112-001
WLAN antenna (single antenna; not illustrated) L45111-001
(7) Hinge Kit (includes left and right hinges) L45117-001
(8) Display rear cover (includes wireless antennas)
For use in models with an HD camera L45110-001
For use in models with an IR camera L51974-001
Cable Kit
Table 3-3 Cable Kit components and their descriptions
Item Description Spare part number
Cable Kit, includes the following parts: L52208-001
(1) Power/USB board cable
(2) Card reader board cable
(3) Touchpad cable
(4) Fingerprint sensor cable
Cable Kit 21
