HP ProBook 455R G6 User Manual

Battery connector board
Table 6-6 Battery connector board description and part number
Description Spare part number
Battery connector board L45086-001
Before removing the battery connector board, follow these steps:
1. Prepare the computer for disassembly (Preparation for disassembly on page 32).
2. Place the computer in Battery Safe mode (Battery Safe mode on page 32).
3. Remove the bottom cover (Bottom cover on page 33).
4. Remove the battery (Battery on page 41).
Remove the battery connector board:
1. Remove the two Phillips M2.0 × 2.5 screws (1) that secure the board to the computer.
2. Rotate the battery side of the board upward (2), and then pull the board away from the connector on the
system board (3).
Reverse this procedure to install the battery connector board.
48 Chapter 6 Removal and replacement procedures for authorized service provider parts

HP ProBook 455R G6 Specifications

General

Operating System	Windows 10 Pro
Processor	AMD Ryzen 5 3500U
Graphics	AMD Radeon Vega Graphics
Display	15.6-inch, 1920 x 1080 pixels
RAM	Up to 32GB DDR4
Storage	256GB SSD
Weight	2.0 kg
Battery	3-cell, 45 Wh Li-ion
Ports	1 x USB-C, 1 x HDMI, 1 x headphone/microphone combo
Wireless	Bluetooth 4.2
