Installing the 5400zl Switches
Example Network Topologies
Installing the 5400zl
Switches
Example Network Topologies
This section shows a few example network topologies in which the 5400zl
switches can be implemented. Although these examples show the

6-slot chassis, the principles are the same for the 12-slot chassis.
Basic Connectivity
Figure 2-14. Basic Switch Connectivity
The 5400zl switches can provide basic network connectivity to a high number
of PoE or PoE+ devices. These devices can be easily connected, as shown in
the above illustration.
5400zl Switch
Phones, APs and other peripherals
