HP ProCurve 5400zl

2-30
Installing the 5400zl Switches
Example Network Topologies
Installing the 5400zl
Switches
Figure 2-17. Guaranteeing 10 Gbps on a specific port.
1
-
GbE Module Ports
14.4 Gbps
Channel
4 2
14.4 Gbps
Channel
3
Port A1 is guaranteed 10
Gbps because it does
not need to share the
channel with port A4
Ports A2 and A3 share this channel
in a trunked link, which fairly
balances the 14.4 Gbps
bandwidth between the two ports
Port 4 is
not used
A
1
(X2)
10-GbE Ports
14.4 Gbps
Channel
A4
(X2)
A2
(CX2)
14.4 Gbps
Channel
A3
(CX2)
in a trunked link, which fairly
balances the 14.4 Gbps
Port 4 is
not used
Switch
