Rear panel components
NOTE: Your computer model may look slightly dierent from the illustration in this section.
Item Icon Component Item Icon Component
1 Antenna cover 7 Dual-Mode DisplayPort (2)
2 Thumbscrew 8 USB 3.1 Gen 1 ports (2)
3 USB 3.1 Gen 1 port 9 Optional port
One of the following ports may be used:
DisplayPort, HDMI, VGA, USB Type-C, or
serial port
4 Security cable slot 10 USB 2.0 port
5 External antenna connector (optional) 11 RJ-45 (network) jack/status lights
6 Padlock loop 12 Power connector
Serial number location
Each computer has a unique serial number and a product ID number that are located on the exterior of the
computer. Keep these numbers available for use when contacting support for assistance.
2 Chapter 1 Product features
