HP ProDesk 400 G5 Desktop Mini User Manual

Drive cage
1. Prepare the computer for disassembly (Preparation for disassembly on page 15).
2. Remove the access panel (Access panel on page 16).
3. Remove the hard drive (Hard drive on page 20).
4. Lift the connector latch on the system board (1), and then disconnect the hard drive cable using the pull
tab on the cable (2).
5. Remove the two Torx T15 screws (3) that secure the hard drive cage to the chassis.
6. Slide the hard drive cage back, and then lift it out of the chassis (4).
To install the drive cage, reverse the removal procedure.
22 Chapter 4 Removal and replacement procedures

HP ProDesk 400 G5 Desktop Mini Specifications

General

Chipset	Intel Q370
Memory	Up to 32 GB DDR4-2666 SDRAM
Operating System	Windows 10 Pro
Power Supply	65 W external power adapter
Processor	Core™ i3, Core™ i5, Core™ i7 (8th Gen)
Storage	Up to 2 TB HDD
Graphics	Intel UHD Graphics 630
Form Factor	Desktop Mini
Ports (Front)	1x headphone/microphone combo; 2x USB 3.1 Gen 1
Ports (Rear)	2x USB 2.0; 2x USB 3.1 Gen 1
Dimensions	177 x 175 x 34 mm
Weight	1.26 kg
Network	Gigabit Ethernet
Wireless	Bluetooth 5.0
