Hood sensor module
Follow these steps to remove the hood sensor module:
1. Prepare the computer for disassembly (see Preparation for disassembly on page 20).
2. Remove the access panel (see Access panel on page 21).
3. Position the computer with the rear panel toward you.
4. Disconnect the hood sensor module cable (1) from the system board.
5. Release the hood sensor module (2) from the retention clip built into the computer chassis.
6. Remove the hood sensor module.
Reverse this procedure to install the hood sensor module.
Hood sensor module 27
