HP ProLiant DL320 Generation 2

Removal and Replacement Procedures
6. Lift the processor locking lever (1) and lift the processor from the socket (2).
Figure 2-34: Removing the processor from the system board
Reverse steps 1 through 6 to reinstall the processor and heatsink.
CAUTION: Always use a new heatsink when replacing processors. Failure to use new
components may result in damage to the processor.
HP ProLiant DL320 Generation 2 Server Maintenance and Service Guide 2-39
