HP ProLiant DL980 G7 - Front Bezel

To replace the component, reverse the removal procedure.
Front bezel
CAUTION: Removal of the bezel will most likely destroy the component. Have a replacement
bezel on hand for immediate replacement before removing the bezel.
1. Power down the server.
2. Extend the server from the rack.
3. Remove the access panel.
4. Remove the SID bezel (“Systems Insight Display assembly” (page 57)).
5. Remove the seven screws from the right side of the chassis and eight screws from the left side
of the chassis.
6. From the left and right insertion tabs, slide the upper part of the bezel forward.
58 Removal and replacement procedures
