HP ProLiant DL980 G7 - I;O Expansion Board

To replace the component, reverse the removal procedure.
For more information about battery replacement or proper disposal, contact an authorized reseller
or an authorized service provider.
I/O expansion board
CAUTION: To prevent improper cooling and thermal damage, do not operate the server unless
all expansion slots have either an expansion slot cover or an expansion board installed.
NOTE: When either optional I/O expansion board in installed in a two-processor configuration,
the second processor must be installed in socket 3.
1. Power off the server (“Power off the server” (page 22)).
2. Extend the server from the rack.
3. Remove the access panel.
4. Release the latches on the release lever.
I/O expansion board 61
