Removal and replacement procedures 56

Lift the system board out of the chassis.

To replace the system board:

1. Install the system board.

2. Connect all cables disconnected from the failed system board.

3. Install the DIMMs.

4. If removed, install the dedicated iLO management port.

5. Install the expansion boards.

CAUTION: Failure to completely open the processor locking lever prevents the processor from

seating during installation, leading to hardware damage.

CAUTION: To avoid damage to the processor, do not touch the bottom of the processor,

especially the contact area.
