Removal and replacement procedures 47
8.
Open each of the processor locking levers in the order indicated, and then open the processor
retaining bracket.
CAUTION: THE PINS ON THE SYSTEM BOARD ARE VERY FRAGILE AND EASILY
DAMAGED. To avoid damage to the system board, do not touch the processor or the
processor socket contacts.
9. Remove the processor from the processor retaining bracket.
