2-6
Status
Port Summary
Table 2-3. Port Summary Fields
■ Click Clear to reset all statistics to their initial values.
■ Click the Refresh link above the page to re-display the page with the latest port information.
For instructions on configuring port settings, see “Port Configuration” on page 4-1.
Field Description
Port Summary
Interface List of physical and logical interfaces supported or configured on a particular platform.
Physical Type Displays whether the port is operating in copper mode or fiber mode.
Port Status The physical status (up or down) of the link at the port.
AutoNeg Status Displays whether Auto negotiation is enabled or disabled on the port.
Link Speed The physical speed at which the port is operating.
MTU The Maximum Transmission Unit (MTU), also referred to as Max Frame size acceptable
on the specified port.
Port Statistics and Trunk Statistics
Note: The following statistics are collected for both individual port and for trunks.
Interface/Trunk List of physical and logical interfaces supported on that platform.
Received Packets w/o Error The packet count received on the port with out any packet errors.
Received Packets with Error The packet count received on the port with errors.
Broadcast Received
Packets
The packet count for Broadcast packets received on the port.
Transmitted Packets w/o
Errors
The number of packets transmitted out of that port with out any packet errors.
Transmitted Packets with
Errors
The number of packets transmitted out of the port with packet errors.
Collisions The number of packet collisions.
Transmitted Pause Frames The number of Ethernet pause frames transmitted. (This information is collected for ports
but not for trunks.)
Received Pause Frames The number of Ethernet pause frames received. (This information is collected for ports
but not for trunks.)
