C Power-on Self Test (POST) error codes
This appendix lists the error codes that can be returned by HP Smart Array Controller Option ROM
during Power-On Self Test (POST), and provides details of corrective actions you can take.
POST error codes
The Smart Array Controller provides diagnostic error messages to the server BIOS at reboot. Many
of these POST messages are self-explanatory and suggest corrective actions for troubleshooting.
Detailed information and corrective actions are listed in Table 20.
The Level column in Table 20 indicates the severity of the error:
None No F1 prompt is triggered.
Informational An F1 prompt is triggered, unless a POST prompt timeout is configured.
Critical The controller always requests the System ROM to display the F1 prompt,
although this can still be disabled through system configuration.
Table 20 Smart Array controller POST error codes
Corrective actionLevelDescriptionError
code
Replace the controller if this error
persists after restarting the system.
CriticalSlot z Drive Array Controller - Redundant ROM
Reprogramming Failure.
1713
Backup ROM has been activated.
Check firmware version.
CriticalSlot z Drive Array Controller - Redundant ROM
Checksum Error.
1714
Replace the controller if this error
persists.
CriticalSlot z Drive Array Controller – Memory Error(s)
Occurred Warning: Corrected Memory Error(s)
were detected during Controller memory self-test...
1715
Note the physical disk that has been
identified as failing.
InformationalSlot z Drive Array - S.M.A.R.T. Hard Drive Detects
Imminent Failure Port 1I: Box 1: Bay 2
1720
Note the physical disks that have been
identified as failing.
InformationalSlot z Drive Array - Drive Parameter Tracking
Predicts Imminent Failure.
1721
The following drives should be replaced when
conditions permit: Port 1I: Box 1: Bays 2, 3.
None.InformationalSlot z Drive Array - Physical Drive Position
Change(s) Detected - Logical drive configuration
has automatically been updated.
1724
None.InformationalSlot z Drive Array - Array Accelerator Memory
Size Change Detected.
1726
Array Accelerator configuration has automatically
been updated.
Reduce the number of logical drives
in the system. See Chapter 3:
“Configuration” (page 40).
Critical if lost
logical drives;
otherwise
Informational
Slot z Drive Array - New Logical Drive(s)
Attachment Detected.
(if more than 32 logical drives are configured, this
will be followed by:)
1727
Auto-configuration failed: Too many logical drives.
Data loss may have occurred. Contact
your HP support representative for
assistance.
CriticalSlot z Drive Array - Abnormal Shut-Down Detected
with Write-Cache Enabled.
No Array Accelerator battery backup on this
model array controller. Any data that may have
been in Array Accelerator memory has been lost.
1728
POST error codes 111
