Smart Array P812 controller features
Board components and features
Figure 12 HP AM312A Smart Array P812 controller components
6 7
1 3
4 52
53
Port 5I (Mini SAS 4i
connector).
1
Ports 1E, 2E, 3E, and 4E
(Mini SAS 4x connectors).
Capacitor pack for cache
module.
42
Cache module (Also known
as array accelerator).
Port 6I (Mini SAS 4i
connector).
Smart Array P812 controller board runtime LEDs
The Smart Array P812 Controller board has 10 runtime LEDs that indicate activities and error
conditions.
16 Controller overview
