HP StorageWorks 8/20q Fibre Channel Switch Installation and Reference Guide 71
Fabric management specifications
Weight and physical dimensions
Electrical specifications
Table 13 Fabric management specifications for the 8/20q Fibre Channel Switch
Specification Description
Management methods Command Line Interface
FTP
GS-3 Management Server
Simple SAN Connection Manager
graphical user interface
QuickTools web applet
SMI-S
SNMP
TFTP
Maintenance connection RS-232 connector; null modem F/F DB9
cable
Ethernet connection RJ-45 connector; 10/100 BASE-T cable
Switch agent Allows a network management station to
obtain configuration values, traffic
information, and failure data pertaining to
the Fibre Channels using SNMP through the
Ethernet interface.
Table 14 Switch physical dimensions for the 8/20q Fibre Channel Switch
Property Value
Height 1U or 43.2 mm (1.70 in)
Width 432 mm (17 in)
Depth 305 mm (12.0 in)
Weight 4.08 kg (9 lb)
with zero SFPs installed
Table 15 Electrical specifications for the 8/20q Fibre Channel Switch
Specification Description
Operating voltage 100 to 240 VAC; 50 to 60 Hz
Power source loading (maximum) 1 A at 120 VAC/0.5 A at 240 VAC
Heat output (maximum) 100 watts
Circuit protection Internally fused
