Tape Drive Installation and Replacement
391U Rackmount Tape Enclosure Reference Guide
Note: Make sure that all of the posts are engaged into their respective slots in the drive
mounting rails.
Figure 29: Installing the tape drive
13. Attach the power cable 1, SCSI data cable 3, and SCSI ID cable 2 (if used)
removed in step 7. See Figure 30.
Figure 30: Attach cables to the drive
15106
2
1
3
15109
1
2
3
