Table 9 Power specification at 240V, both racks installed (continued)
BTU/hourAVWA2–rack configuration
32496.209470.869127.4436.464 couplets with minimum storage
71424.2020437.6619696.5682.064 couplets with maximum storage
PDU options
NOTE: HP recommends using one of the Monitored PDU options.
The HP B6200 Backup System is available with the following power options.
Table 10 Monitored PDU part numbers
InternationalNorth America and Japan
48A 380-415V
nl
32A 200-240V
nl
24A 200-240V
nl
40A 200-240V
nl
Output
3 Phase1 Phase3 Phase1 Phase
IEC60309 516P6IEC60309 332P6NEMA L15-30PCS8265AConnector plug type
IEC60309 4 pole, 5
wire, 380-415 VAC,
IEC60309 2 pole, 3
wire 32A; Hubbell
NEMA L15-30RHubbell CS8264C,
CS82269 or
equivalent
Connector socket type
16A; HubbellC332C65, C33R6S
or equivalent C516C6S, C516R6S
or equivalent
4444Quantity required per
rack
AF507AAF509AAF503AAF505APart number
Table 11 Modular PDU part numbers
InternationalNorth America and Japan
40A High Voltage
INTL - 200-240V
nl
32A High Voltage
INTL - 200-240V
nl
40A High
Voltage INTL
-200-240V
nl
40A High Voltage
NA/JP - 200-240V
nl
1 Phase
24A High Voltage
NA/JP - 200-240V
nl
1 Phase
Output
1 Phase1 Phase
1 Phase
IEC 60309 63A
nl
IEC 309-32A
nl
Field wired
terminal
CS8265C 50ANEMA L6-30PConnector
plugtype
(IEC 363P6S)(IEC 332P6S)
IEC 60309 2 pole,
3 wire,
IEC60309 2 pole,
3 wire
Hard wired to
power outlet
CS8264C or
CS8269, 50A or
equivalent
NEMA L6-30RConnector socket
type
200-240VAC,200-240VAC,
63A; IEC32A; IEC
363C6S, 36R6S
or equivalent
332C6S, 332R6S
or equivalent
nl
not
nl
available
252663-B32252663-B31252663-B21252663-D73252663-D72Part number
24224Quantity required
per rack
8 Product specifications
