HP Uninterruptible Power System T1000 XR and T1500 XR Models User Guide 3-1
HP CONFIDENTIAL Codename: Sherman Part Number: 216164-002 Last Saved On: 8/19/02 4:21 PM
3
Configuration
This chapter contains information on configuring the UPS. Proper configuration of the UPS is
important in performing other functions on the unit, such as maintaining the battery and
troubleshooting alarms.
Placing the UPS in Configure Mode
The UPS can enter Configure mode while in Operate or Standby mode.
To place the UPS in Configure mode:
1. Remove the front bezel by snapping the bezel off (1).
1
Figure 3-1: Removing the UPS front bezel

HP T1500 XR Specifications

General

Form Factor	Tower
Interface	USB
Frequency	50/60 Hz
Battery Type	Sealed lead-acid
Topology	Line Interactive
Transfer Time	4 ms
Operating Temperature	0°C to 40°C
Humidity	0% to 95% non-condensing
Storage Temperature	-4°F to 122°F (-20°C to 50°C)
