HP Uninterruptible Power System T1000 XR and T1500 XR Models User Guide C-1
HP CONFIDENTIAL Codename: Sherman Part Number: 216164-002 Last Saved On: 8/19/02 4:21 PM
C
Specifications
This appendix provides the physical, input, and output specifications for the UPS. Topics also
include battery descriptions, battery runtime estimates, and environmental requirements when
operating the UPS.
Physical Specifications
Table C-1: Physical Specifications—UPS T1000 XR Models
Feature Metric U.S.
Dimensions Width 163 mm 6.4 in
Height 241 mm 9.5 in
Depth* 411 mm 16.2 in
Weight 13 kg 34.5 lb
* With UPS front bezel installed
Table C-2: Physical Specifications—UPS T1500 XR Models
Feature Metric U.S.
Dimensions Width 163 mm 6.4 in
Height 241 mm 9.5 in
Depth* 462 mm 18.2 in
Weight 24 kg 55 lb
*With UPS front bezel installed

HP T1500 XR Specifications

General

Form Factor	Tower
Interface	USB
Frequency	50/60 Hz
Battery Type	Sealed lead-acid
Topology	Line Interactive
Transfer Time	4 ms
Operating Temperature	0°C to 40°C
Humidity	0% to 95% non-condensing
Storage Temperature	-4°F to 122°F (-20°C to 50°C)
