HP T1500 XR User Manual

Specifications
HP Uninterruptible Power System T1000 XR and T1500 XR Models User Guide C-3
HP CONFIDENTIAL Codename: Sherman Part Number: 216164-002 Last Saved On: 8/19/02 4:21 PM
Output Specifications
Table C-4: Output Specifications—UPS T1000 XR and T1500 XR Models
UPS Model
Effective
VA
Nominal Power
Rating (W)
Load
Segment #
Output Receptacles
T1000 XR NA 1000 700 1 3 x 5-15R
2 3 x 5-15R
T1000 XR H INT’L 1000 700 1 3 x IEC-320, C13
2 3 x IEC-320, C13
T1500 XR NA 1440 1050 1 3 x 5-15R
2 3 x 5-15R
T1500 XR JPN 1500 1050 1 3 x 5-15R
2 3 x 5-15R
T1500 XR H INT’L 1500 1050 1 3 x IEC-320, C13
2 3 x IEC-320, C13

HP T1500 XR Specifications

General

Form Factor	Tower
Interface	USB
Frequency	50/60 Hz
Battery Type	Sealed lead-acid
Topology	Line Interactive
Transfer Time	4 ms
Operating Temperature	0°C to 40°C
Humidity	0% to 95% non-condensing
Storage Temperature	-4°F to 122°F (-20°C to 50°C)
