Configuration
HP Uninterruptible Power System T1000 XR and T1500 XR Models User Guide 3-3
HP CONFIDENTIAL Codename: Sherman Part Number: 216164-002 Last Saved On: 8/19/02 4:21 PM
Table 3-2: Available Voltage Settings
UPS Model Available Settings
Utility Voltage (VAC)
Parameter (LED)
T1000 XR NA 100 General Alarm ( )
110 On Battery ( )
120 (default)
Bad Battery/Low Battery (
)
127 Utility LED ( )
T1000 XR H INT’L 220 On Battery ( )
230 (default)
Bad Battery/Low Battery (
)
240 Utility LED ( )
T1500 XR NA 110 On Battery ( )
120 (default)
Bad Battery/Low Battery (
)
127 Utility LED ( )
T1500 XR JPN 100 General Alarm ( )
T1500 XR H INT’L 220 On Battery ( )
230 (default)
Bad Battery/Low Battery (
)
240 Utility LED ( )
