Installation 10
IMPORTANT: Do not use the battery if the recharge date has passed. If the date on the battery recharge
date label has passed without the battery being recharged, contact an HP authorized service representative
for directions.
Connecting the batteries
WARNING: The unit contains sealed lead-acid battery modules. To prevent fire or
chemical burns:
Do not attempt to recharge batteries after removal from the unit.
Do not disassemble, crush, or puncture the batteries.
Do not short the external contacts of the batteries.
Do not immerse the batteries in water.
Do not expose to temperatures higher than 40°C (104°F).
WARNING: To prevent personal injury from hazardous energy:
Remove watches, rings, or other metal objects.
Use tools with insulated handles.
Do not place tools or metal parts on top of batteries.
IMPORTANT: Before performing the following tasks, be sure that the unit is powered down and
disconnected from the utility power source.
1. Remove the UPS front bezel.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP T750 and is the answer not in the manual?

HP T750 Specifications

General IconGeneral
Output Voltage230V
Input Voltage230V
Interface PortUSB
Waveform TypeStepped approximation to a sinewave
Nominal output voltage230V
Nominal input voltage230V
Battery TypeSealed lead-acid (VRLA)
TopologyLine Interactive
Input frequency50/60 Hz
Output ConnectionsIEC 320 C13
Input connection typeIEC 320 C14
Typical recharge time8 hours
Audible alarmYes
Operating Temperature0 - 40 °C
ApprovalsCE
Frequency50/60 Hz
Control panelLED status indicators
Operating Relative Humidity5% to 95% non-condensing
