HP T750 User Manual

Specifications 24
UPS model VA
Nominal power
rating (W)
Nominal voltage
setting
T750 INTL 750 500 220, 230, 240
Voltage specifications
Configuration setting (VAC) Available nominal output voltage (VAC)
100 100
110 110
120 120
220 220
230 230
240 240
Output tolerance specifications
Source of power Regulation
Utility power (nominal
range)
-10% to +6% of nominal output voltage rating
(within the guidelines of the Computer Business
Equipment Manufacturers Association)
Battery power ±10% of nominal output voltage rating
Output feature specifications
Feature Specification
Online efficiency 94% nominal input voltage
Voltage wave shape Sine wave; 5% THD with typical PFC load
Surge suppression High-energy 6500 A peak
Noise filtering
MOVs and line filter for normal and common mode
use
Battery specifications
Feature Specification
Type
Each model contains maintenance-free, sealed, valve regulated
lead-acid batteries with a 3-year minimum float service life at
25°C (77°F).
Voltage The battery modules have a battery string voltage of 24 V.
Charging
Complete charge takes no more than 24 hours. After
approximately 4 hours, the batteries reach 90% charge at
default nominal utility voltage and no load.

HP T750 Specifications

General

Output Voltage	230V
Input Voltage	230V
Interface Port	USB
Waveform Type	Stepped approximation to a sinewave
Nominal output voltage	230V
Nominal input voltage	230V
Battery Type	Sealed lead-acid (VRLA)
Topology	Line Interactive
Input frequency	50/60 Hz
Output Connections	IEC 320 C13
Input connection type	IEC 320 C14
Typical recharge time	8 hours
Audible alarm	Yes
Operating Temperature	0 - 40 °C
Approvals	CE
Frequency	50/60 Hz
Control panel	LED status indicators
Operating Relative Humidity	5% to 95% non-condensing
