HP T750 User Manual

Installation 12
Output voltage Input voltage range DIP switch 2 DIP switch 1
120 V* 108–127 V Down Down
T750 INTL 220 V 198–233 V Up Down
230 V 207–243 V Up Up
230 V* 207–243 V Down Down
240 V 216–254 V Down Up
Connecting the host computer
CAUTION: Use only the computer interface cable supplied with the UPS to connect the communications
port to the host computer.
Connect the UPS to a host computer using either the USB cable or the DB9 serial cable included with the
UPS. Install HP Power Manager software 4.0 or later on the host computer. See the HP website
(http://www.hp.com/go/rackandpower
) to download the latest version of HP Power Manager.
NOTE: To install and configure the software, see the software user guide. The software user guide is
available for download from the HP website (http://www.hp.com/go/rackandpower
).
Connecting the serial communications port

HP T750 Specifications

General

Output Voltage	230V
Input Voltage	230V
Interface Port	USB
Waveform Type	Stepped approximation to a sinewave
Nominal output voltage	230V
Nominal input voltage	230V
Battery Type	Sealed lead-acid (VRLA)
Topology	Line Interactive
Input frequency	50/60 Hz
Output Connections	IEC 320 C13
Input connection type	IEC 320 C14
Typical recharge time	8 hours
Audible alarm	Yes
Operating Temperature	0 - 40 °C
Approvals	CE
Frequency	50/60 Hz
Control panel	LED status indicators
Operating Relative Humidity	5% to 95% non-condensing
