NOTE: The display enclosure is available using the following spare part numbers:
809574-001 for red models
809573-001 for silver HP Pavilion x360 Convertible models
809575-001 for green HP Pavilion x360 Convertible models
816503-001 for purple HP Pavilion x360 Convertible models
824201-001 for silver HP x360 310 G2 models
a. Use a thin plastic tool to run along the entire seam of the display to loosen the cover from the
display.
CAUTION: Top avoid damaging the display, be sure to only run the tool in one direction.
b. Separate the left side (1), top (2), right side (3), and bottom (4) of the display cover from the
display.
NOTE: Separate the cover from display just enough to gain access to the touch control cable that
routes to the connector on the board on the side of the display panel.
The raw display panel is available using spare part number 809548-001 for SVA panels and
809549-001 for UVWA panels.
56 Chapter 5 Removal and replacement procedures for Authorized Service Provider parts
