HP x360 310 G2 User Manual

c. Disconnect the cable from the touch control board (1), and the separate the display enclosure from
the display (2).
Position the display enclosure next to the display panel so you can access the display cable
connected to the back of the display panel.
d. Disconnect the display cable from the back of the display panel by lifting the tape that secures the
cable in the connector (1), and then pull the cable out of the connector (2).
The display cable is available using spare part number 809576-001.
2. To remove the webcam module:
NOTE: The webcam is available using spare part number 807542-001.
a. Lift the webcam module (1) enough to gain access to the cable.
Component replacement procedures 57

HP x360 310 G2 Specifications

General

Graphics	Intel HD Graphics
Processor	Intel Celeron N3060
RAM	4 GB DDR3L
Storage	500 GB HDD
Display	11.6-inch HD (1366 x 768)
Operating System	Windows 10 Home
Battery	3-cell Li-ion
Ports	HDMI, headphone/microphone combo
Wireless	Bluetooth 4.0
