HP Z400 - Workstation

f. Tighten the four cold plate retention screws (see Installing the CPU heatsink on page 128).
Figure 5-60 Tightening the cold plate screws
9. Connect the LCS pump cable to the system board as shown in the following figure.
Figure 5-61 Connecting the LCS pump cable
122 Chapter 5 Replacing components ENWW
