HP Z440 Workstation Series Service Manual

HP Z440 Workstation chassis components
1 Fan 10 System board
2 Hard drive carrier 11 Rear system fan and holder
3 Hard drive, 3.5-inch 12 Chassis
4 Side access panel 13 Speaker
5 Memory fans 14 PCIe card
6 Heat sink 15 Front bay filler (optional)
7 Processor 16 Optical drive, slim
8 Memory module (DIMM) 17 Front bezel
9 Power supply
4 Chapter 1 Hardware overview

HP Z440 Workstation Series Specifications

General

Chipset	Intel C612
Memory Slots	8 DIMM slots
Audio	Integrated Realtek HD ALC221 Audio
Processor Options	Intel Xeon E5-1600 v3 series; Intel Xeon E5-2600 v3 series
Memory	Up to 128 GB DDR4-2133 ECC
Graphics Options	NVIDIA Quadro or AMD FirePro professional graphics cards
Power Supply	700W 90% efficient, wide-ranging, active Power Factor Correction (PFC)
Operating System	Windows 10 Pro, Windows 7 Professional, or Linux
Weight	11 kg
Network	Integrated Intel I218LM PCIe GbE
Expansion Slots	1 PCIe Gen2 x1, 1 PCI
