HP Z440 Workstation Series Service Manual

HP Z640 Workstations — Intel AHCI SATA controller guidelines
See
HP Z640 Workstation system board components on page 11 to determine the location of system board
connectors.
NOTE: sSATA port 0 is the default port for the boot drive (the default port can be changed manually in the
BIOS).
RAID card (RC) or system
board (SB) connector
Drive installation scenarios
123
RC J8
SAS HDD 1 SAS HDD 1-B SATA HDD 1-B
RC J7 SAS HDD 2 SATA HDD 2-D SAS HDD 2-D
RC J6 SAS HDD 3 SATA HDD 3-D SAS HDD 3-D
RC J5 SAS HDD 4 SATA HDD 4-D SAS HDD 4-D
SB SATA 0 — — —
SB SATA 1 — — —
SB SATA 2 ODD 1 ODD 1 ODD 1
SB SATA 3 ODD 2 ODD 2 ODD 2
SB SATA 4 eSATA (top) eSATA (top) eSATA (top)
SB SATA 5 eSATA (bottom) eSATA (bottom) eSATA (bottom)
eSATA = external SATA (2 ports per cable assembly)
HDD = hard drive
ODD = optical drive
NOTE: Only the most common configurations are shown here.
62 Chapter 3 Component replacement information and guidelines

HP Z440 Workstation Series Specifications

General

Chipset	Intel C612
Memory Slots	8 DIMM slots
Audio	Integrated Realtek HD ALC221 Audio
Processor Options	Intel Xeon E5-1600 v3 series; Intel Xeon E5-2600 v3 series
Memory	Up to 128 GB DDR4-2133 ECC
Graphics Options	NVIDIA Quadro or AMD FirePro professional graphics cards
Power Supply	700W 90% efficient, wide-ranging, active Power Factor Correction (PFC)
Operating System	Windows 10 Pro, Windows 7 Professional, or Linux
Weight	11 kg
Network	Integrated Intel I218LM PCIe GbE
Expansion Slots	1 PCIe Gen2 x1, 1 PCI
