HP Z440 Workstation Series Service Manual

About this guide
This guide provides service and maintenance information, technical details and configuration guidance for
the HP Z440, Z640, and Z840 Workstations.
IMPORTANT: Removal and replacement procedures are now available in videos on the HP website.
Go to the HP Customer Self-Repair Services Media Library at
http://www.hp.com/go/sml.
Guide topics
Hardware overview on page 1
System management on page 23
Component replacement information and guidelines on page 45
Diagnostics and troubleshooting on page 76
Configuring password security and resetting CMOS on page 98
Linux technical notes on page 102
Configuring RAID devices on page 105
System board designators on page 115
NOTE: View the HP Z440, Z640, and Z840 Workstation Series User Guide at http://www.hp.com/support/
workstation_manuals.
iii

HP Z440 Workstation Series Specifications

General

Chipset	Intel C612
Memory Slots	8 DIMM slots
Audio	Integrated Realtek HD ALC221 Audio
Processor Options	Intel Xeon E5-1600 v3 series; Intel Xeon E5-2600 v3 series
Memory	Up to 128 GB DDR4-2133 ECC
Graphics Options	NVIDIA Quadro or AMD FirePro professional graphics cards
Power Supply	700W 90% efficient, wide-ranging, active Power Factor Correction (PFC)
Operating System	Windows 10 Pro, Windows 7 Professional, or Linux
Weight	11 kg
Network	Integrated Intel I218LM PCIe GbE
Expansion Slots	1 PCIe Gen2 x1, 1 PCI
