HP Z440 Workstation Series Service Manual

HP Z840 Workstation chassis components
1 Processor heatsinks (primary and secondary) 11 Rear system fans
2 Hard drive carrier 12 Power supply
3 Hard drive 13 Chassis
4 Processor/memory fans 14 Front system fans (two fans with 1125 W power supply)
5 Side access panel 15 PCI card guide
6 Processor 16 Optical drive, slim
7 Second processor (optional) 17 Front bay filler
8 Memory module (DIMM) 18 Media card reader
9 PCI Retainer 19 Front bezel
10 System board 20 PCIe card
HP Z840 Workstation components 17

HP Z440 Workstation Series Specifications

General

Chipset	Intel C612
Memory Slots	8 DIMM slots
Audio	Integrated Realtek HD ALC221 Audio
Processor Options	Intel Xeon E5-1600 v3 series; Intel Xeon E5-2600 v3 series
Memory	Up to 128 GB DDR4-2133 ECC
Graphics Options	NVIDIA Quadro or AMD FirePro professional graphics cards
Power Supply	700W 90% efficient, wide-ranging, active Power Factor Correction (PFC)
Operating System	Windows 10 Pro, Windows 7 Professional, or Linux
Weight	11 kg
Network	Integrated Intel I218LM PCIe GbE
Expansion Slots	1 PCIe Gen2 x1, 1 PCI
