HP Z440 Workstation Series Service Manual

HP Z440 Workstation installation sequence recommendations
Load
order
Card description Slot 1 Slot 2 Slot 3 Slot 4 Slot 5 Slot 6
1 First PCIe graphic card Only
2
Second PCIe graphic card or
Tesla C2075
Only
3 Third PCIe graphic card Only
4 Fourth PCIe graphic card Only
5 SAS card 2nd 1st 3rd
6 Z Turbo Drive 1st 3rd 1st 2nd
7 Z Turbo Drive 2nd 2nd 1st
8 PCIe 1394b card 1st 2nd
9 PCIe audio card 1st 2nd 3rd 4th
10 PCIe NIC card (LAN) 1st 2nd 3rd 4th
11 e-SATA bulkhead kit 2nd 3rd 1st
12 Second serial port kit 2nd 3rd 1st
NOTE: Slot sequenced from the rear I/O aperture to the board edge.
Component replacement guidelines 53

HP Z440 Workstation Series Specifications

General

Chipset	Intel C612
Memory Slots	8 DIMM slots
Audio	Integrated Realtek HD ALC221 Audio
Processor Options	Intel Xeon E5-1600 v3 series; Intel Xeon E5-2600 v3 series
Memory	Up to 128 GB DDR4-2133 ECC
Graphics Options	NVIDIA Quadro or AMD FirePro professional graphics cards
Power Supply	700W 90% efficient, wide-ranging, active Power Factor Correction (PFC)
Operating System	Windows 10 Pro, Windows 7 Professional, or Linux
Weight	11 kg
Network	Integrated Intel I218LM PCIe GbE
Expansion Slots	1 PCIe Gen2 x1, 1 PCI
